WebChat

WebChat (web chat) is a function that allows interactive text communication between the client and the contact center agent in real time. The conversation is recorded in the database, the agent can associate an issue with or attach contact information to the conversation. The chat also includes an indication of whether the chat can be started (open/closed) and the management of waiting for a free agent.

Important

WebChat is an application of the WebSite module. Before you can use it, you must install and configure it.

Overview and options

WebChat is always initiated by the website visitor. The chat window can appear right after the visitor enters the website or after a pre-defined delay time. Once the first message has been sent, it is distributed to agents based on the relevant conditions.

WebChat allows website visitors to ask for help and ask questions directly from the browser environment. The text conversation is preserved even when switching between pages, even if the visitor opens more than one page at a time.

The ability to chat with a contact center agent may be hidden outside of business hours. The chat window can display information about the availability of agents, etc.

Note

In the following pictures you will see the default apperance (without your modifications).

Minimized and maximized form

The chat window can take two forms:

  • minimized form (reduced) – The minimized state occupies only the header.

    ../../_images/chat-inactive-minimized.en.png
  • maximized form (normal form used during conversation) – The maximized chat window contains the header, conversation, and footer.

    ../../_images/chat-inactive-open.en.png

You can style the appearance of individual parts very differently from the default appearance. For example, a minimized chat can look like a bubble:

../../_images/webchat-min-max1.nol10n.gif

Header

../../_images/chat-header-parts.en.png

The chat window header consists of an icon [1], a title bar [2], minimize and maximize buttons [3] and additional text [4].

You can control the presence and appearance of each part of the header by configuration and styles. The default appearance is the same in both the minimized and the maximized form.

The part with the icon [1] can

  • Display an icon of the current agent called avatar. Before the agent is assigned, the visitor will see a silhouette icon. After assignment, they will see the assigned agent’s avatar.

  • Always display the same icon (e.g. company logo)

  • Show no icon

The section with the title [2] can display:

  • Webchat status only (e.g. “connecting”)

  • The agent’s name only

  • The agent’s name and webchat status

  • Webchat status and the agent’s name

  • Anything customized according to the template

The part with min/max buttons [3] can be:

  • Visible

  • Hidden (even when buttons are hidden you can always min/max by tapping on the header)

There can be additional text [4] below the icon and the title. This is typically used for information about operating hours, phone numbers, etc. Additional text can be:

  • Always the same for both the min and the max form

  • Different for the min and the max forms

Chat

The largest part is taken up by the conversation between the visitor and the agent.

../../_images/webchat-customize-in-out-messages.en.png

Footer

../../_images/footer-parts.en.png

At the bottom left there is an area for writing a message, which can show the following icons (listed from the top):

  • The agent’s positive or negative evaluation

  • Insert emoticons into the message

  • Insert an attachment

    Caution

    Not available in this version yet; you can only display the icon but it will not do anything. This feature is being prepared for the next version.

The last one on the right is the Send message button. Apart from this button, you can also use Enter when entering a name or sending a message.

Supported browsers

Chat works reliably in the following web browsers:

  • IE 9+

  • Edge

  • Chrome

  • Firefox

Adjusting the layout

WebSite templates

WebSite templates are used to customize the appearance and layout of WebChat. You can find them in the administration in the Configuration ‣ WebSite routing ‣ WebSite templates section.

Note

Currently, the only application that uses WebSite templates is WebChat.

The WebSite template is a set of three files.

  • An HTML template that generates a code embedded in a web page,

  • CSS styles of this HTML template, and

  • a JSON object that sets the way how the chat operates and appears.

These files can be stored on the server disk, or their contents are stored in a database and the files are created on the fly. If they are real files, they must be in the Content folder of the WebSite web application and named webchat.css, webchat.json, webchat.html.

The advantage of having the files stored in the database is convenient editing in the administration in the Configuration ‣ WebSite routing ‣ WebSite templates section. Additionally, you can create multiple templates and assign them to WebChat applications.

The template and the settings files are cached on the server side for ScriptCaching (parameter from WebSite’s web.config file).

Before sending to the browser, the ##WebSiteAddress## element is macro-expanded in that WebSiteAddress is replaced (a parameter from WebSite’s web.config).

The HTML template is designed so that almost everything can be done without the need to edit it using JSON object attributes or CSS styles.

Caution

If you still need to interfere with the HTML template, you should contact FrontStage support to help ensure that the modified template will work with all layout options, customization options, and supported browsers.

No default HTML template uses inline styles (<div style="...">) and all styles are in CSS templates. The only styles outside the CSS template are the calculated heights of the boxes used to show or hide content according to the detected browser.

DataURL for images

DataURL (sometimes referred to as DataURI, but RFC 2397 mentions DataURL) is a URL with the data: schema (e.g. HTTP has a http:// schema) and contains binary data encoded with Base64. The advantage of this method is that no external files are needed as their content follow data:.


All icons and images used for WebChat are inserted using DataURL, so there is no need to access the server to upload files (issues with rights, security etc.).

Height and width

Height

The WebChat height is defined in the JSON object in the ChatBoxHeight attribute with the default value of 500px. The value has the following restrictions:

  • The smallest possible height must be 300px

  • If the browser height is lower than the value specified in the JSON object and, at the same time, the height is at least 300px, the maximum possible size will be set as the height so that WebChat is completely readable even at lower resolutions

  • If the browser height is lower than the value specified in the JSON object and, at the same time, the height is not at least 300px, the WebChat height from the JSON object will be used.

It is possible to define one additional height parameter in the JSON object in the ChatBoxClosedHeight attribute. The default value is 200px. It specifies what the Webchat height should be when the signal is closed, when it is not possible to communicate with agents and only an informational message about possible unavailability of agents or opening hours is displayed after the Webchat is clicked.

Width on desktop and mobile

The chat width on the desktop is defined in the JSON attribute ChatBoxWidth; the default value is set to 400px. Due to the lengths of the header text and avatar, the narrowest recommended width is 290px.

You can request different chat widths on mobile and desktop. The ChatBoxWidth value is only used when the available size is larger than the ChatBoxMobileWidth (the responsive breakpoint at which the mobile starts). Otherwise, it will expand to the full available width of the window.

../../_images/webchat-closed-minimized.en.png

Header

The default appearance is with the avatar being the agent’s photo, with additional text.

../../_images/webchat-with-personalized-avatar-with-text.en.png

The look is the same in both the minimized and the maximized form, but you can use styles to differentiate it. For example, the minimized header can look like a bubble:

../../_images/webchat-min-max1.nol10n.gif

Default attribute values affecting the minimized form:

  • "MiniHeaderAgentAvatarShow": false - Do not show the agent’s avatar.

  • "MiniHeaderIndividualText": false - The same additional text as in the max form (literal SubtitleChat).

Default values for maximized appearance:

  • "HeaderAgentAvatarShow": false - Do not show the agent’s avatar.

  • "HeaderTitle": '" - Show WebChat status and do not follow the template.

Title

The HeaderTitle attribute can have several values:

Value

Description

"" (empty string)

Display the status only - e.g. “Available operators”, “Notifying agent”, etc.

"agentname"

Show only the agent’s name (the default text is WebChat status, once the agent has been assigned, the status changes to the agent’s name).

"agentnameandstatus"

Show the agent’s name and status - without active communication only “Available operators”, “Notifying agent”, after assigning agent “Jiří - Conversation with agent”.

"statusandagentname"

(inverse to agentnameandstatus) Show the agent status and name - without active communication only “Available operators”, “Notify agent”, after assigning agent “Conversation with agent - Jiri”.

"template"

Display is controlled by the template in the HeaderTitleTemplate attribute (.. reference to the default value in the attribute reference at the end…).

If "HeaderTitle": "template", the title is built according to the HTML template HeaderTitleTemplate. The default value of the template is

<span class='##Hidden##'>##AgentName##</span><span class='icc3-chat-header-title-in'>(##DataFrom##)</span>

You can use the following placeholders in the template: (none is mandatory; the template can contain none, one or all of the placeholders).

Placeholders

Description

##DataFrom##

Lists the WebChat status

##AgentName##

Prints the agent’s name after the assignment

##Literal##

An additional text according to LL HeaderTitle

##Hidden##

A reactive CSS class value. When the agent is not present, it hides the HTML (DOM) element (display: none); otherwise, it displays with a space after (padding-right). In the result, the visitor will see (I am alerting the agent)'' or ``George (I am alerting the agent).

Important

A title longer than the space allotted will be truncated.

Additional text

The additional text can be as long as you like and is always displayed in full. It is always displayed, and if it is long, it takes away space from the conversation. The recommended length is therefore a short message with a few words, e.g. “Welcome to us!”.

Set the desired text in the SubtitleChat literal. You can set a different additional text with WebChat minimized using the IndividualSubtitleChat literal.

No avatar, no additional text

This is the smallest possible appearance of WebChat (with the least information).

  1. No avatar - set the JSON attribute HeaderAgentAvatarShow to false.

  2. No title - set the JSON attribute HeaderTitle to "" (empty string)

  3. No additional text - Do not fill in the SubtitleChat literal (it must be present but empty).

No avatar, with additional text

  1. No avatar - set the JSON attribute HeaderAgentAvatarShow to false.

  2. Additional text - Set the desired text in the SubtitleChat literal.

../../_images/webchat-no-avatar-with-text.en.png

With an avatar as the agent’s photo, with additional text

An avatar icon that changes to an agent photo when the agent is assigned.

  1. General avatar before assigning agent - Set the JSON attribute HeaderAgentAvatarShow to true.

  2. Individual agent avatar - Set the JSON attribute HeaderIconAvatarUrl to the path using which the browser can build the URL of the agent avatar image.

    E.g. /Content/img/##AgentId##.jpg, where ##AgentId## is a placeholder that is replaced by the agent ID. The file for an agent with ID e.g. 4354b36d-e2ab-46ad-bc78-347edcd9b293 must be available (saved) as /Content/img/4354b36d-e2ab-46ad-bc78-347edcd9b293.jpg.

  3. Additional text - Set the desired text in the SubtitleChat literal.

../../_images/webchat-with-personalized-avatar-with-text.en.png

With the same avatar for everyone, with additional text

Instead of a common avatar, you can use, for example, your company logo.

  1. Enable avatar - Set the JSON attribute HeaderAgentAvatarShow to true.

  2. Identical avatar - Either put the DataURL image in the JSON attribute HeaderIconAvatar OR enter the avatar URL using HeaderIconAvatarUrl.

  3. Additional text - Set the desired text in the SubtitleChat literal.

Hiding the exit icon

The exit icon can be hidden if the CloseIcon attribute in the JSON file is empty: "CloseIcon: "".

Footer

At the bottom there is a text box (<textarea>) for writing a message. By default, it is one line high.

../../_images/webchat-customize-footer.en.png

Changing the height

To change the height, edit the rows attribute in the template HTML code. For example, to set a height equal to three lines:

<textarea id="icc3-chat-textinput" maxlength="4096" rows="3"></textarea>

Note

It is not recommended to set more than three lines.

Other icons

This is followed by icons for rating, inserting an emoticon and inserting an attachment. The last button is used to send the message.

To display the icon

  • of positive rating, use the JSON attribute of ThumbUpIcon

  • of negative rating, use the JSON attribute of ThumbDownIcon

  • of emoticons, use the JSON attribute of EmoticonsIcon

  • for adding an attachment, use the JSON attribute of AttachmentIcon

The icon will be displayed if its attribute in the JSON object has a filled path; if the value is an empty string, it will be hidden. It does not matter if the image URL is used or the image is embedded as a DataURL.

Initial display

Before starting a chat with an agent, you can customize how the WebChat window will appear to the visitor.

Welcome phrase and one piece of information

Before starting a chat, you can ask the visitor for one piece of text information (e.g. name). It is not mandatory to fill in the information.

  1. Set the JSON attribute ContentWelcomeTextShow to true.

  2. Set the literals

    • For the welcome text use the `` Welcome`` literal.

    • The description of the button used to start a chat can be set using the StartChat literal.

    • Placeholder text of the input text field (to be used as <input placeholder=...>) by the TypeYourName literal

  3. In the administration, under Configuration ‣ WebSite routing, select WebChat and

    • In the Remote peer name source field, select Explicit field.

    • Nothing must be selected in the Scenario field; otherwise, only the welcome message will be displayed.

Displaying a scenario (form)

Before starting a chat, you can show the visitor a scenario (form). Before submission, the required fields are checked and, if there are errors, the form is not submitted.

For this way of displaying, you must set the following fields for the WebChat application in the administration section Configuration ‣ WebSite routing:

  • Scenario to a prearranged script

  • Remote counterparty name source to the value of the Form field.

Show nothing

Nothing is displayed before the first message is sent.

To use this type of display, it is necessary in the administration section of Configuration ‣ WebSite routing for WebChat to set a value other than Form field and Explicit field in the Remote counterparty name source field.

../../_images/webchat-overview.en.png

Emoticons

../../_images/webchat-customize-emoticons.en.png

If an icon for inserting an emoticon is displayed (non-empty JSON attribute EmoticonsIcon), you can customize their menu with the JSON attribute Emoticons.

The value is a semicolon-separated list of characters. E.g. 😁;😂;😐;😉;😒;😬;😞;😪;😲;😡;😴;⌚;💡;👍;👎;💰;. These are not images, but Unicode characters for emoticons and, therefore, they may differ depending on the browser, operating system and font used.

Bubble in minimized state

If you do not like the default appearance of the minimized WebChat, you can try the bubble look. Just add the following style sheet to the end of the CSS file.

.icc3-chat-header-close #icc3-chat-header-top {position:absolute;width:50px !important;height:50px !important;padding:0 !important;border-radius:50px !important;bottom:54px !important;right:80px !important;background:#007ac8 !important;}
.icc3-chat-header-open #icc3-chat-header-status-out, .icc3-chat-header-open #icc3-chat-header-status, .icc3-chat-header-close #icc3-chat-header-title, .icc3-chat-header-close #icc3-chat-header-icons {display:none !important;}
#icc3-chat-header-status-out {width:16px;height:16px;border-radius:16px;background:#fff;position:absolute;bottom:-1px;right:-1px;}
#icc3-chat-header-status {width:10px;height:10px;border-radius:16px;background:#eee;position:absolute;bottom:2px;right:2px;}
#icc3-chat-header-agent img.icc3-chat-header-icons-chat {margin:13px 10px 0 13px;}

Customizing behavior

Termination

There are several ways to end a web chat:

  • The time set in the administration section Chat and ICR ‣ Gateways in the field Inertia and Inactivity expires.

  • The agent terminates the chat (issue settled).

  • Termination by the visitor (cross if the Close button display is enabled by the non-empty JSON attribute CloseIcon)

Termination by visitor

../../_images/webchat-close1.en.png ../../_images/webchat-close2.en.png

After pressing the cross in the header, you will be asked if you really want to chat. After pressing the button for “yes”, the chat will end and the window will minimize.

The texts are configurable with the PopupCloseTitle, PopupCloseYes, and PopupCloseNo literals.

Exit by visitor with rating

Termination with rating in the JSON object by setting EndChatWithRatingShow with the following possible values:

  • "none" - no rating

    ../../_images/webchat-closing-none.en.png
  • "emoji" –- rating using three emoticons - smileys

    ../../_images/webchat-closing-emoji.en.png
  • "stars" - five-star rating

    ../../_images/webchat-closing-stars.en.png
  • "thumb" –- rating in the form of thumbs up or down

    ../../_images/webchat-closing-thumb.en.png

The text of the rating prompt is set by the PopupCloseRating literal.

The responses are stored as events of type RatingIn (50) in the table ChatEvent, column Text. This has the syntax known to WebSite - + and - are relative shifts, ! are absolute values.

The current value is kept in the Chat.Rating column. The default value is 0.

Blocking WebChat in Busy and Closed states

If the client wants to block WebChat from being displayed when the state is Busy or Closed, set the JSON attribute BlockedChatOnBusyAndClosed to true.

If the chat is blocked, you can explain to the visitor why they cannot talk to you.

../../_images/webchat-closed-minimized.en.png

To modify the Busy status message, set the BusyBlockedChat literal. E.g. “All our agents are busy. Chat is unavailable.”

To modify the message for the Closed state, set the literal ClosedBlockedChat. E.g. “All our agents are unavailable. Chat is unavailable.”

Termination and refresh times

Termination and refreshing are managed by two JSON attributes:

  • CloseTimeout - How long (in ms) the WebChat window remains open after the visitor exits the chat.

  • RefreshTimeAfterCloseStatus - How long (in ms) it will take to reopen the chat after the visitor exits it.

Customizing inbound and outbound messages

../../_images/webchat-customize-in-out-messages.en.png

Templates

The default HTML template for inbound and outbound messages is defined in JSON by the SentenceHtmlOut and SentenceHtmlIn attributes.

"SentenceHtmlOut": "-##Confirmed##-<span class='icc3-chat-msgs-info'><span class='icc3-chat-msgs-time icc3-chat-msgs-##ClassTime##' data-time='##DataTime##'>##Time##</span></span><span class='icc3-chat-msgs-out icc3-chat-msgs-out-##Class##'><img class='icc3-chat-msgs-out-img-left' src='##AgentImage##' alt='##AgentName##'><img class='icc3-chat-msgs-out-img-right' src='##AgentImage##' alt='##AgentName##'><span class='icc3-chat-msgs-out-text'>##Text##<strong title='##Time##'>&nbsp;##PartyName##</strong></span></span>"

-##Confirmed##-<span class='icc3-chat-msgs-info'><span class='icc3-chat-msgs-time icc3-chat-msgs-##ClassTime##' data-time='##DataTime##'>##Time##</span></span><span class='icc3-chat-msgs-in icc3-chat-msgs-in-##Class##'><strong title='##Time##'>##PartyName##:&nbsp;</strong>##Text##</span>

In both templates you have the following placeholders available:

  • ##Confirmed## – Information about whether the message is confirmed (delivered to the counterparty); either the value “Ctrue” or “Cfalse”.

  • ##AgentAvatar### – Agent image usable in HTML (<img src=...>) or CSS(background-url: ...). Either URL or DataURL.

  • ##AgentName## – The agent’s name

  • ##PartyName### – The visitor’s name, if filled in. Otherwise, usually “Me” (or another value of the DefaultPartyName literal).

  • ##Text## – Message text

  • ##Class## and ##ClassTime## – The value from the JSON attribute SentenceHtmlHorizontalPosition to build the CSS class name.

  • ##Time## – Message time. Display method according to SentenceHtmlTimeType.

  • ##DateTime## – The time of the message. The value is used for the internal HTML5 data attribute data-time, which is needed for the relative “5 minutes ago” style time display.

E.g. by deleting <span class="icc3-chat-msgs-info"> through to </span>, you will remove the message time, or by deleting <img src='##AgentAvatar##' alt='##AgentName##'> in SentenceHtmlOut you will remove the agent’s avatar.

Settings

  • Where the first message will come from - an attribute of the JSON file SentenceHtmlVerticalPosition (top - the first message at the top), (bottom - the first message at the bottom)

  • Whether the agent’s messages will be on the right or left - an attribute of the JSON file SentenceHtmlHorizontalPosition (left, right)

  • How messages will be added - an attribute of the JSON file SentenceHtmlAppend (top - first message at the top, last message at the bottom), (bottom - first message at the bottom and last message at the top)

  • How the time will be displayed for messages - JSON file attribute``SentenceHtmlTimeType`` (1 - absolute (a specific time), 2 - relative (it is reactive - texts like “delivered a minute ago” or “delivered just now” etc.))

Merging messages in the same minute

For each message sent in chat, the time when the message was sent is displayed. If the messages were sent in quick succession, within one minute, you can override the time display in such a case.

This is handled by the SentenceHtmlTimeMerge JSON attribute. Possible values:

  • False - Time is displayed for each message; default behavior (i.e. the same behavior without the specified attribute)

  • True - The time, which would be duplicated in this case, is shown only once at the beginning of the message block. The message “bubbles” are visually closer together, creating more space for text

    ../../_images/1648-webchat-timemerge-param.en.png

Using the attribute does not affect the time style setting, i.e. SentenceHtmlTimeType (see above).

Important

Attribute available from Webchat Version 9.

Configuring FrontStage

Setting up ChannelUsage

In order for a given FrontStage installation to be able to use WebChat, you must enable the WebIM channel in the configuration parameter ChannelUsage.

Gateways

A list of gateways used by the system to transmit chat communication; they will serve as entry points. You cannot delete items as it is necessary to maintain a reference from the chat history table.

You can find them in the administration in the Chat and ICR ‣ Gateways section; the fields have the following meaning from WebSite’s viewpoint:

Field

Description

Name

Name for administration

Description

A free description for administration

Channel

As which channel will conversations be presented in FrontStage; the usual setting for WebSite is “WebIM”

Direction

Gateway options to receive new conversations (I), create new conversations (O), or both; only Option I is considered for WebSite.

Peer

Address - a technical address in the ProServer address used by the installed WebSite application; it must match the “PeerAddress” parameter in the web.config file of the relevant WebSite installation; example: in the case of a single WebSite installation, an address scheme based on the application name can be used, so “!iCC.WebSite” is used both here and in web.config.

Inertia

In seconds. If the agent ends the conversation (with the Settle button) or the chat is terminated due to inactivity, the interval during which the chat is reactivated when the visitor on the site sends another replica (i.e. all replicas and all acquired metadata will be preserved); after this time, on the contrary, the chat will be established as a completely new one (however, all chats of the given TrackingId can be listed in the related communications).

Inactivity

In seconds. An interval during which the system monitors whether a message has been sent by any party, and if not, the chat is automatically terminated.

Gateway conditions

Gateway conditions determining what gateway status should be signaled outward towards visitors. The conditions are evaluated based on the page script request according to the rank; the first matching condition is used.

You can find them in the administration in the Chat and ICR ‣ Gateway conditions section and from WebSite’s viewpoint; the individual fields have the following meaning:

Parameters

Field

Description

Name

Name for administration.

Description

A free description for administration.

Rank

The order in which the rules are evaluated.

Condition actions

Field

Description

Signal

Resulting signaled status (Free, Busy, Closed, Hidden)

Scenario

Not used for WebSite/WebChat

Terms of conditions

Not filled means that the condition does not apply.

Field

Description

Gateway

Applies only to chat coming through the gateway

Does it already have an external tracking ID open?

  • Yes - The condition applies if the visitor (or their TrackingId) already has an active chat.

  • No - The condition applies if the visitor (or their TrackingId) has no active chat.

Note

Using this rule for WebChat with a standard script is not useful because if a visitor has an active chat, they are presented with this chat and not the gateway status; it can be used by third-party scripts though.

Culture (ISO)

A two-character language code that is provided by the browser as the user’s preferred language. Example: cs.

User token mask

An SQL LIKE mask testing for UserToken string match; example: USER%

External processing mask

An SQL LIKE mask testing for ExtResponse string match

Project

An indication of which project is to be used to calculate the following dynamic data. If empty, it will apply to the entire FrontStage regardless of the Project.

Caution

Dynamic data is calculated regardless of the language.

Fewer agents logged in than

The system dynamically calculates the number of agents logged in, and if there are fewer of them than the set number, the condition applies.

Agents available fewer than

The system dynamically calculates the number of agents in statuses that allow chat distribution (see Agents/Statuses - Distribute Chat), and if there are fewer of them than the set number, the condition applies.

Queue longer than

The system dynamically calculates the number of chats in the Waiting status; if their number is greater than the set number, the condition applies.

Request frequency over [per minute]

The system monitors the number of chat messages of type ES_CHAT_REQUEST, ES_CHAT_START and ES_CHAT_SENTENCE for type M_Sentence (i.e. from people) for the whole FrontStage, and if this number is greater than the set number, the condition applies.

Calendar mode, From, :guilabel: To

The time condition specifies how the From/To fields are interpreted. If it is empty, then time is not checked. The time used is the local time of the FrontStage server.

  • Annually (DayInYear) - valid on a specific day of the year, every year, time from/to

  • One time (SingleDay) - valid on a specific date (including year), time from/to

  • Weekly (DayInWeek) - valid on a specific day of the week, every week, time from/to

  • Weekly (inverted) (NotDayInWeek) - an inverted condition to DayInWeek, i.e. not valid on a specific day of the week, every week, time from/to

  • When entering the time “from”, the system sets the seconds to 00.0, for the time “to” it sets the seconds to 59.9.

  • Example for entering the entire morning: 8:00 to 11:59

Chat project conditions

Chat project conditions that specify how metadata should be assigned to an inbound chat for distribution purposes. The conditions are evaluated based on the chat start (ES_CHAT_START); the first matching condition is used.

You can find them in the administration in the Chat and ICR ‣ Project conditions section and, from WebSite’s viewpoint, the individual fields have the following meaning:

Parameters

Field

Description

Name

Name for administration

Description

A free description for administration

Rank

The order in which the conditions are evaluated.

Condition actions

Field

Description

Project

The project to be assigned to the chat; it determines the type of the agent’s skill.

Skill

The minimum level of agent skill required

Priority tab

Priority in distribution (the higher the number, the higher the priority)

Preferred agent

An option to indicate which agent should serve the chat; if the agent is in a status that allows distribution, the chat will be distributed to them regardless how busy the agent is.

Language tab

The chat language; it determines the type of the agent’s language proficiency required.

Proficiency

The minimum required level of the agent’s language proficiency

Terms of conditions

Not filled means that the condition does not apply.

Field

Description

Directory

When searching for contact data, a matching entry (PhoneNumber) was found and it belongs to the given phonebook.

Gateway

Applies only to chat coming through the gateway

Culture (ISO)

A two-character language code that is provided by the browser as the user’s preferred language; example: cs

User token mask

An SQL LIKE mask testing for UserToken string match; example: USER%

External processing mask

An SQL LIKE mask testing for ExtResponse string match

Set of conditions

A set of conditions that checks the current chat conversation (conducted in the ICR) and, if the chat shows a match, the condition applies.

Calendar mode, From, :guilabel: To

The time condition specifies how the From/To fields are interpreted. If it is empty, then time is not checked. The time used is the local time of the FrontStage server.

  • Annually (DayInYear) - Valid on a specific day of the year, every year, time from/to

  • One time (SingleDay) - Valid on a specific date (including year), time from/to

  • Weekly (DayInWeek) - Valid on a specific day of the week, every week, time from/to

  • Weekly (inverted) (NotDayInWeek) - An inverted condition to DayInWeek, i.e. not valid on a specific day of the week, every week, time from/to

  • When entering the time “from”, the system sets the seconds to 00.0, for the time “to” it sets the seconds to 59.9.

  • Example for entering the entire morning: 8:00 to 11:59

ICR mask

An SQL LIKE mask testing for IcrResponseA string match (originating from ICR processing)

Conditions for agent to accept a chat

To receive a chat, the agent must have:

  1. Appropriate project skills for the WebIM channel.

  2. Adequate language proficiency.

  3. A workplace supporting chat.

    The agent identifies chat support at their workplace by the chat icon in the login portlet:

    ../../_images/agent-login2.png
  4. Corresponding complexity or capacity condition. In the administration in the Agents section, set a complexity or capacity condition for agents.

  • If FrontStage is operating in the separated queue mode, then it is necessary to set the appropriate Web chat difficulty for the agent. This value tells you how many chats the agent is capable of serving at one time. For example, 100 means 100% workload by one chat (i.e. only one chat can be managed at a time).

  • If in the unified queue mode, select the corresponding Used capacity rule for the agent. This selection box determines the agent capacity for a given channel and the mutual limitation of channel distribution depending on the current agent status.

Localization

Texts of group 102 (WebSiteLocalisation) are needed in localization, LiteralLookup table.

Deciding the localization language is primarily defined by the particular apliacation rule. However, to avoid the mapping for every single rule settings (it would lead to a multiplication of rules by the amount of lng localizations), you can define it with help of virtual app of Lang type.

If the localization is not determined from the application rules (e.g. WebChat), then the system will try to determine the mapping according to the Lang application (all conditions are evaluated in the usual way). If even this evaluation does not provide data, then the default value of DefaultLangugage from web.config will be used.

Extending the localization with other languages is possible by adding items (e.g. using an analogous script as above) to the LiteralLookup table. Changing localization texts is possible directly in the LiteralLookup table, with the values being cached on the server side with the DatabaseCaching refresh interval.

Texts in the localization can contain HTML tags directly if the information is to be formatted or expressed in some way, e.g. by means of images.

Logging and debugging

Logging

See also

General information about WebSite logging.

WebChat event types:

  • WebChatApp (0) - Download the script from ~/scripts/webchat.js, EventData=URL of the page that downloads the script; this event is always logged, regardless of the status of the LogEvent switch in the WebSiteRouting condition (among other things, it is because the conditions are not evaluated in any way for downloading the script).

  • WebRoutingChatNone (11) – The calling of ~/api/routing/webchat, which was served by the calculation (not from the cache) when no chat is active; EventData=URL of the page where the script is running; Referenceid – an ID of the WebSiteRouting condition that was used; Result – the indicated gateway status (Signal – Free, Busy, Closed, Hidden)

  • WebRoutingChatCached (11) – The calling of ~/api/routing/webchat, which was served from the cache when no chat is active; EventData=URL of the page where the script is running; Referenceid – an ID of the WebSiteRouting condition that was used; Result – the indicated gateway status (Signal)

  • WebRoutingChatRunning (12) – The calling of ~/api/routing/webchat, which was served while the chat is active; EventData=URL of the page where the script is running; Referenceid – the ChatId of the ongoing chat; Result – the indicated chat status (Alerting, ICR, Waiting, ICR, Alerting, Answered, Closed)

  • WebRoutingChatBlocked (13) – The calling of ~/api/routing/webchat, during which a condition with a block flag was found; EventData=URL of the page where the script is running; Referenceid – an ID of the WebSiteRouting condition that was used

  • WebRoutingUserAgent (20) - Additional information accompanying the WebRoutingChatXXX events; the events are generated only if the request contained the QueryString parameter with IncludeSettings=true (in the standard script only after reloading the page); EventData=UserAgent (browser information); Result=PreferedCulture.

  • WebRoutingUserToken (20) – Additional information accompanying the WebRoutingChatXXX events; the events are generated only if the request contained the QueryString parameter with IncludeSettings=true (in the standard script only after reloading the page); EventData=UserToken (optional user information); Result = Template (the template name from the condition used)

Debugging

WebChat can output debugging information to the browser console. To enable debugging log entries to be shown on the console, set the JSON attribute ConsoleLog to true.

Another option is a special page index-chat-debug.html, which lists debugging information, received and sent messages, and the JSON attributes used.

Integration using JavaScript

See also

General information about WebSite application integration using JavaScript.

If the template is not set in the administration, Webchat file is being searched for on the server disc (webchat.html), settings (webchat.json) and styles (webchat.css), located in the Content folder. Default templates have the same names as the application.

Default script template has the .js suffix. The webchat.js file is located in the Content folder. This file is only a template, which is expanded by the dynamic values. If you reffer in the <skript> tag this particular file, chat tab might be displayed, but it won’t work properly. You have to reffer to the virtual Script path.

Embedding into page

To embed WebChat into an HTML page, use the <script> element in the <head> section. Most often as follows:

<script async src="//website/scripts/webchat.js"></script>

Notes:

  • Missing type attribute (type=''text/javascript'') – In HTML5, JavaScript is the default value

  • The path in the src attribute starts with two slashes // – The two slashes mean “whatever protocol is currently in use”. If the HTML page is loaded over HTTP, the script will download over the same protocol. If over HTTPS, the script will do the same. This avoids the browser’s “page contains insecure elements” error.

  • Attribute async – Ensures faster rendering of the page in the browser. The script loaded with async is downloaded in parallel when the page is parsed and evaluated as soon as it is available. Without async, the browser will not finish rendering the page until the script is downloaded, parsed and evaluated.

    Caution

    If you interact with WebChat using a custom JavaScript, you must embed WebChat without async. It will not happen that your JavaScript loads before WebChat. However, the overall page loading will be slightly slower.

Global object

After embedding the script and executing it, you have a WebChat object in the global window object.

This global object is named after the WebChat version. For example, for version 8 icc3_WebChat8, for version 7 icc3_WebCHat7, etc.

A convenient way to override the version in the global object name is to use a construct like this at the beginning of your script,

var icc3_WebChat = window["icc3_WebChat8"] || window["icc3_WebChat7"] || window["icc3_WebChat6"] || window["icc3_WebChat5"];

which stores icc3_WebChat into the icc3_WebChat8 variable if available, otherwise icc3_WebChat7 if available, etc. From this line on, you can use the global object as window.icc3_WebChat.

Due to the different execution times of WebChat.js and your JavaScript, the recommended usage pattern is with if verifying the existence of the object. This will prevent ReferenceError: Can't find variable ..., Uncaught ReferenceError: icc3_WebChat7 is not defined, etc. (error message varies by browser).

if (window.icc3_WebChat) {
   window.icc3_WebChat.HideChat()
}

SignalChangedIn function

When WebChat receives a status change signal, it can call a JavaScript function to react to the change.

If the icc3_SignalChangedIn function is found in the global window viewer object, WebChat calls it and passes two parameters to it:

  • Signal name as a string (e.g. “free agents”, “terminated”)

  • CSS code of the signal color as a string (e.g. “#a7a7aa”) (as set in the JSON attributes SignalFreeBackColor, SignalBusyBackColor and SignalClosedBackColor)

<script>
window.icc3_SignalChangedIn = function(signal, signalColor) {
   // ...
}
</script>

For example, you can write the name of the signal and its color in each element with the given classes:

<script>
window.icc3_SignalChangedIn = function(signal, signalColor) {
    var a = document.getElementsByClassName("icc3-chat-signal-text");
    var b = document.getElementsByClassName("icc3-chat-signal-color");
    if (a) {
        for (var i = 0; i < a.length; i++) {
            a[i].innerHTML = signal || "?";
        }
    }
    if(b) {
        for (var i = 0; i < b.length; i++) {
            b[i].setAttribute("style","background-color:" + signalColor);
        }
    }
}
</script>

Or, for example, replace the text and color of an element with the selected ID:

<script>
window.icc3_SignalChangedIn = function(signal, signalColor) {
    var b = document.getElementById("signalBadge");
    if (b) {
        b.innerHTML = signal || "?";
        b.style.backgroundColor = signalColor;
    }
}
</script>

Hiding and displaying the WebChat window

New in version 8.

The WebChat global object offers two functions for viewing and displaying the WebChat window.

HideChat([forced = false])

Hides the WebChat window.

Arguments
  • forced (boolean()) – If true, it will be hidden even if a conversation is in progress.

ShowChat()

Displays the WebChat window.

Propagating a value from a form to ExtResponse for use in rules

New in version 8.

If the chat is started with the form, you can write the selected form field into the Chat.ExtResponse database column of the chat.

Then use the ExtResponse value for routing using the External processing mask (ExtResponseMask) field in the External processing mask and External processing mask of the chat.

If the icc3_GetExtResponse() function is found in the global viewer object (window), WebChat will call after the visitor submits the form.

icc3_GetExtResponse(webResponse)

A hook called by WebChat after a visitor submits a form.

Returns

A screen control whose value filled in by the visitor is to be stored in the ExtResponse field in the Chat table in the database. The screen control is obtained by calling getFormField().

getFormField(guid)

Returns the screen control of the specified GUID.

Arguments
  • guid (string()) – Screen control.

Returns

A screen control or null if the chat does not have a scenario or the given control.

Examplesof use:

<script>
var icc3_WebChat = window["icc3_WebChat8"] || window["icc3_WebChat7"] || window["icc3_WebChat6"] || window["icc3_WebChat5"];

function icc3_GetExtResponse(webResponse) {
     var ff = icc3_WebChat.getFormField('43515b6f-77fb-4162-a3c6-c0e8cc1e6daf');
     return ff != null ? ff : webResponse;
}
</script>

RefreshFromSignal function

New in version 9.

Important

When implementing the WebChat on a common web pages, the HTML code is being reloaded periodically and routing rules (window.location, HTTP header, …) for particular URL are being evaluated, when the change signal is received. In case of SPA pages, the code is not reloaded during the usage. Routing rules are evaluated only when the web is loaded.

If you would like to reload the routing rules during the usage of SPA, you can call javascript function RefreshFromSignal()

RefreshFromSignal(forced)

Routing rules refresh. Function will do the similar actions like Init function, but without triggering automated countdown for refresh.

Arguments
  • forced (boolean()) – What will be the WebChat behaviour, if the chat is in process and routing rules are changed. * true, chat will be always hidden and chat icon will disappaer form the pages * false, chat window won’t be affected

Note

A similar function is offered by ShowChat and HideChat with the difference that WebSiteRules are not evaluated. This must be handled by the website author.

Functions controlling ChatBox

WebChat can display a solicitation to the user, which is presented in the chat window, and the user can respond to it.

That is handled by JavaScrit functions:

  • icc3_WebChat.RevealChatBox - display the solicitation

    • parametr optionalText - string - contains appeal text, can be NULL

    • Example: icc3_WebChat.RevealChatBox('Need help with something? We're here for you.')

  • icc3_WebChat.ConcealChatBox - hides the solicitation; without parameters

Calling these functions is up to the website author ; they are not bound to time.

Mapping attributes to a form using a JSON object

New in version 8.

If you start a chat with a form, you can populate the field values with your own script.

If WebChat finds the icc3_JsonData object in the global viewer object (window) during creation, it transfers (prefills) the values of its attributes into the same form element (screen control) of the same name.

If it is not a readable element, the element is displayed to the visitor, and the visitor can change the pre-filled value before submission.

The control marked as Read only is hidden for the visitor, but does get sent.

Hidden controls are suitable, for example, for visitor identification:

<script>
var icc3_JsonData = { "CustomerId": "someValue" }
</script>

Formatting the displayed time

Time stamp, visible in agents chat window, can be formated with help of format string. This string is inserted into LiteralLookup database table, Cmn_TimeFormat2 (displayed time) and Cmn_TimeFormat (used as tooltip) parameters.

Characters in the format string can be inserted in upper or lower case. Lower case indicates the one-digit number representation (1, 2, 3, …), upper case indicates two-digit representation (01, 02, 03, …). Numbers bigger than 10 are not affected.

  • “h” / “H” - hours

  • “n” / “N” - minutes (“N” is a JavaScript convention)

  • “s” / “S” - seconds

  • “i” / “I” - twelve hours format (after 12 there goes 1 again)

  • “a” - when used together with i/I, it specifies whether AM/PM should be displayed

Default values (if database created from .dacpac) for cs-CZ and en-US languages:

  • Cmn_TimeFormat2 - “h:N”

  • Cmn_TimeFormat - “h:N:S”

There’s no valid convention for AM and PM, therfore you can specify your own format (am, a.m., …). This can be set in a LiteralLookup table, Cmn_Am and Cmn_Pm parameters.

Implementation example:

static getTimeString(t: Date) {
      return DateTimeHelpers.formatTimeString(t, Lookup.Cmn_TimeFormat);
  }

  static getTimeString2(t: Date) {
      return DateTimeHelpers.formatTimeString(t, Lookup.Cmn_TimeFormat2);
  }

  private static formatTimeString(t: Date, timeFormat: string) {
      if(t == null) {
          return "";
      }
      const hours = t.getUTCHours();
      const h = hours.toString(10);
      const H = h.length == 1 ? "0" + h : h;
      var hours12 = hours > 12 ? hours - 12 : hours == 0 ? 12 : hours;
      const i = hours12.toString();
      const I = i.length == 1 ? "0" + i : i;
      const a = hours < 12 ? Lookup.Cmn_Am : Lookup.Cmn_Pm;
      let N = t.getUTCMinutes().toString(10);
      if(N.length == 1) N = "0" + N;
      let S = t.getUTCSeconds().toString(10);
      if(S.length == 1) S = "0" + S;
      return timeFormat.replace("H", H).replace("h", h).replace("I", I).replace("i", i).replace("N", N).replace("S", S).replace("a", a);
  }

Note

Time used to formated based on the server settings in the past.

This also relates to the option of adjusting the possition of chat time stamp, with help of css classes, so the text is alighned correctly.

Classes are listed in the LiteralLookup table, Chat_StampOutboundCss and Chat_StampInboundCss parameters, individually for every used language.

Default values (if database created from .dacpac) are stamp-outbound (cs-CZ) and tamp-outbound-wide (en-US) classes, for both items in the literal. These classes can be adjusted in portal.css file.

Classes code example:

.stamp-outbound {
 left: -50px;
}

.stamp-inbound {
 right: -50px;
}

.stamp-outbound-wide {
 left: -65px;
}

.stamp-inbound-wide {
 right: -65px;
}

Mapping attributes to a form using a query string (QS)

What is a query string?

A query string is the part of the URL that is meant to pass key-pair style parameters. Since some characters cannot be used in the URL or have different meanings, they must be encoded using percent encoding (also known as URL encoding).

For example, the URL https://frontstage.cc?name=John%20Smith&email=john%40smith.com contains two parameters in the QS: name with the value of John Smith and email with the value of john@smith.com.

Mapping using query string parameters in the URL is another way how to pre-populate a WebChat form for the visitor.

WebChat will look at the URL of the current page after uploading. If it contains a query string, it recognizes the key-value pairs in them and transfers (prefills) the values to the same named form elements (screen controls).

If it is not a readable element, the element is displayed to the visitor, and the visitor can change the pre-filled value before submission.

The control marked as Read only is hidden for the visitor, but does get sent.

Note

If the same field is “pre-populated” in both icc3_JsonData (Mapping attributes to a form using a JSON object) and the query string, then icc3_JsonData takes precedence.

Visitor identification

A visitor to a website with WebChat hosted, i.e. the counterparty to the agent, can be identified in FrontStage in several ways. We identify the visitor using remote party name and remote address.

Identification is important for the agent, so he has the idea who is the customer and can search additional info. Both values can be found during the call in a chat editor.

../../_images/chat-editor-remote-party-name-address.en.png

How this information is obtained depends on the setting of the Remote party name source. and Technical address source. fields in the WebChat routing administration in the Configuration ‣ WebSite routing section.

Counterparty status

In addition to visitor identification, the visitor’s status is also monitored, i.e. whether the visitor is still “alive”, that means whether they still have the web browser open, the internet is not down, etc. The agent thus knows that the visitor is still “listening” and that it makes sense to write to them. Internally, the states are called hot (active, connected, alive) and cold (inactive, disconnected, down).

The agent can distinguish the state by using the icon present in the chat editor. It has a slightly different look in each application:

Application

Active

Inactive

TeamsClient

../../_images/chat-sun-ico.nol10n.png ../../_images/chat-cloud-ico.nol10n.png

ReactClient

../../_images/remote-party-hot.png ../../_images/remote-party-cold.png

Checking whether the counterparty is alive is technically done by WebChat (frontend) sending periodic signals to the server (backend - managed by the ServiceSync service) at intervals of 3 seconds. When they do not arrive, it is clear that there is a problem with the counterparty.

The interval of the control signals is fixed, but you can set the time after which the chat will go to the “cold” state with the ChatColdTimeOut parameter.

Displayed activity/inactivity text, and TeamsClient icons of these states can be localized adjusting the LiteralLookup database table, see:

../../_images/chat-hot_cold-literals.nol10n.png

Shadow pages for co-browsing

Shadow page can be the same as the one visible on internet or it can be altered for agents purposes - like show additional info from the www system (items in shopping cart, login information and so on.)

Shadow page window is being opened as a child window of agents editor (window.open()). Communication between them is realized by window.postMessage()/window.onmessage() function (editor –> shadow page) and window.opener.postmessage()/window.onmessage() (shadow page –> editor). Handed messages are strings, starting with function key word and optionally followed by searialized data.

The following messages need to be implemented for co-browsing:

  1. EnableDataCoBrowsing - the message must be sent by the shadow page, in order to allow the button for data transfer in chat editor; otherwise only paralel navigation is available

  2. GetCoBrowsingData – The received message has no additional data and the shadowing page should respond by sending serialized data with the CoBrowsingData message followed directly by the data.

  3. CoBrowsingData – After the keyword itself, the message received contains data that the shadowing page should apply to the page status to reflect the situation on the visitor side.

HTML templates, styling and settings

Both template file and settings are being cached on the server during the ScriptCaching time span. Before sending it to the browser, template parameter ##WebSiteAddress## is macroexpanded by WebSiteAddress parameter, which is located in the web.config.

Caution

We recomend to deny access to the Content folder on a production environtment, with help of http (ACL rights or on the IIS level)

Default visual representation

Chat is not active. Reduced and normal status:

../../_images/chat-inactive-minimized.en.png ../../_images/chat-inactive-open.en.png

Chat is active, enlarged status:

../../_images/chat-active-minimized.en.png ../../_images/chat-active-open.en.png

Default HTML template

<div id="icc3-chat-header">
    <div id="icc3-chat-header-top">
        <div id="icc3-chat-header-agent"></div>
        <div id="icc3-chat-header-title"></div>
        <span id="icc3-chat-header-status-out"></span>
        <span id="icc3-chat-header-status" class=" icc3-chat-signal-color"></span>
        <div id="icc3-chat-header-icons">
            <span id="icc3-chat-header-icons-maxi"></span>
            <span id="icc3-chat-header-icons-mini"></span>
            <span id="icc3-chat-header-icons-close"></span>
        </div>
    </div>
    <div id="icc3-chat-header-bottom"></div>
</div>
<div id="icc3-chat-box">
    <div id="icc3-chat-header-separator"></div>
    <div id="icc3-chat-popup">
        <span id="icc3-chat-popup-title"></span>
        <span id="icc3-chat-popup-btn1"></span>
        <span id="icc3-chat-popup-btn2"></span>
    </div>
    <div id="icc3-chat-welcome"></div>
    <div id="icc3-chat-adhoc"></div>
    <div id="icc3-chat-party"><input id="icc3-chat-textparty" type="text" maxlength="320"></div>
    <div id="icc3-chat-btn"></div>
    <div id="icc3-chat-form"></div>
    <div id="icc3-chat-msgs"></div>
    <div id="icc3-chat-bottom">
        <div id="icc3-chat-input">
            <div id="icc3-chat-textarea">
                <textarea id="icc3-chat-textinput" maxlength="4096" rows="1"></textarea>
            </div>
            <div id="icc3-chat-inputs">
                <div id="icc3-chat-inputs-special">
                    <span id="icc3-chat-thumb-up"></span>
                    <span id="icc3-chat-thumb-down"></span>
                    <span id="icc3-chat-emoticons"></span>
                    <span id="icc3-chat-attachment"></span>
                </div>
                <input id="icc3-chat-btninput" type="button">
            </div>
        </div>
        <div id="icc3-chat-copy"></div>
    </div>
    <div id="icc3-chat-emoticons-block">
        <span id="icc3-chat-emoticons-close"></span>
        <div id="icc3-chat-emoticons-icons"></div>
    </div>
    <div id="icc3-chat-attachment-block">
        <span id="icc3-chat-attachment-close"></span>
        <div id="icc3-chat-attachment-input"></div>
    </div>
</div>

Demo

To facilitate integration, the application also includes several demo pages that show the method of integration and procedures for implementing co-browsing. The simplest page is in the default application directory and is called index-chat.html. The content is shown in the example at the beginning of the chapter.

A more comprehensive demo is stored in the “Demo” folder, namely the SimplePage1.html, SimplePage2.html and SimplePage3.html files. The pages allow you to test parallel navigation, Page 2 then enables sending co-browsing data. ShadowPage1.html, ShadowPage2.html and ShadowPage3.html “shadow pages” are created for “public pages” to demonstrate co-browsing.

Tip

In the production environment, we recommend deleting the index-chat.html file and the Demo/ folder.

Integration using REST API

See also

General information about WebSite application integration using REST API.

Routing

See also

General information about Logging.

  • TargetElementID- identification, how the chat app should be displayed; if NULL, it should be as overlay; if item ID is inserted, it should be displayed in this item (typically DIV); third-party scripts can use this parameter as they like.

  • WebResponse - A free parameter (up to 32 characters) that can be passed on to a page or third-party script; this string (from the WebSiteRouting condition) is used to evaluate the ChatGateResponse conditions.

  • Signal - Indicates how the status of the chat gateway should be presented (according to the ChatGateCondition conditions).

    • Free - chat is functional and the presumption is, that customer will connected to the agent immediatelly (or IMR)

    • Busy - The chat is not working, but it is assumed that the visitor will wait for the agent to pay attention to them.

    • Closed - chat is functional, but closed (out of office hours). If some conversation will start, customer will chat with IMR.

    • Hidden - The chat is functional, but it should not be rendered (similar to when NULL is returned); if a conversation is started, it will probably be rejected.

  • ChatRunning - if NOT NULL, it indicates, that there’s ongoing conversation for given TrackingId; field ChatModel contains the same structure, which is sent by WebChat [GET] function.

  • Scenario - The structure of the [ScenarioModel] form, which should be presented to the user to be filled out before the chat starts.

  • PartyName - The name that the visitor gave to themselves when starting the WebChat/Start [POST] conversation. The page script can use it to persist this data.

  • HtmlTemplate - An expanded template (file) stored on the server side in the Content folder, with the .html extension and selected using the WebSiteRouting conditions; the field is sent only if it is requested by the “IncludeSettings” parameter; the default name is webchat.html.

  • Settings - An expanded JSON dictionary structure of key-value stored on the server side in the Content folder, with the .json extension and selected using the WebSiteRouting conditions; the default name is webchat.json.

  • Literals - JSON dictionary-like structure (key-value) stored in iCC database, LiteralLookup table, group 102 (localization determined by WebSiteRouting rules). The field is sent only when requessted by IncludeSettings parameter.

  • SolicitationTimeOut - time [s], after which the script prompts the customer to start writing something (start the chat)

  • SolicitationDuration - time [s], for which the chat prompt will be displayed to the customer

  • WebSiteRoutingId - An ID of the condition that is used for the page.

API

[POST] ~/api/WebChat/Start - (ResultModel must be present in the request). The answer will be a ChatModel structure (200-OK indication) and the chat will start (associates ChatId with TrackingCookie) or if the chat is already going on, it will continue (TrackingCookie already associated) and returns the full chat structure.

Field in sent request [ResultModel]:

  • UserToken - A free string of up to 320 characters designed to distinguish server-side requests; it can be used, for example, to indicate whether a visitor is logged in or not, etc.; it can be evaluated by the ChatPreCondition, ChatProjectCondition, ChatPostCondition, ChatWaitingPostCondition conditions; it is an optional field.

  • ExtResponse - A free string of up to 32 characters, intended to be processed by the ChatPreCondition, ChatProjectCondition, ChatPostCondition, ChatWaitingPostCondition conditions; an optional field.

  • ScenarioId - scenario ID according to which was the form filled. Can be NULL, if no form associated at the start. If any form has been requested as a part of Routing info, then this can be used. Optional field.

  • Values - Values of the associated form; an optional field

  • PartyName - The counterparty’s name as it should be stated during the conversation (if it is not filled in, the application will use the default name “WebSite”).

  • Location - chat starting URL (this info is an alternative to the HTTP Referrer header; if not present in some case, then the param is optional)

  • WebSiteRoutingId - An ID of the condition that is used for the page.

Field in [ChatModel] answer - see next paragraph

[GET] WebChat - Returns the full structure of ChatModel.

Field in [ChatModel] answer:

  • ChatId - ID identifying the chat in iCC DB, can be used for integration on the web’s side

  • AgentId - agent which serves the chat - if the chat is in Alerting or Answered states (in some cases also for Closed state)

  • AgentName - The agent’s name or the counterparty’s (machine) name; it does not have to be filled in.

  • Counter - number of the messages (both directions) in the conversation from it’s start (as it’s stored on the server)

  • IsTyping - An indication that the counterparty is typing.

  • Status - chat status indication

    • Pilot - chat was registered in the database and is waiting for the rules evaluation

    • ICR - An automatic conversation takes place according to the conditions.

    • Waiting - no free agent available, system not communicating

    • Alerting - The chat is indicated to the agent, the system is waiting for the agent to accept it.

    • Answered - A conversation with the agent is in progress.

    • Closed - The chat was terminated either by the agent or by an external party or due to inactivity.

  • Sentences – A field of SentenceModel structures; even after the chat starts, it may contain items because it may be a reactivation of a previously terminated chat; in general, this field can only contain a part of the conversation, so the client must pay attention to the Counter field for each message and keep the messages that it received earlier and did not receive in this field as valid

Conversation replica structure [SentenceModel]:

  • Text - The message text (has no limited length, but it may be limited by web server parameters).

  • IsOutbound - message direction: true - from agent to customer, false - from customer to agent; client app desn’t have to fill this value in the outbound messages, because server does so automatically

  • PartyName - The visitor’s party name for the given message (max. 320 characters).

  • Counter - A serial number of the message (numbered from 1).

  • TimeSent - time of message being sent - RFC format, can be indicated to the customer

  • IsConfirmed - Indication that the message has been delivered to the other party, the information can be indicated to the visitor.

  • Location - URL origin of the chat (this info is also used as an alternative to the HTTP Referrer header, if this is not present, not mandatory parameter) - only valid for messages whis has browser –> server direction

[GET] ~/api/WebChat/*counter* - returns chat structure (ChatModel) beggining with the COunter message number (numbered from 1); if the provided number is higher then server has registered, the request is delayd by the server up to 30 seconds (it enables the implementation of long-polling); simultaneously sent POTS leads to immediate requst processing.

Field in the [ChatModel] answer, see previous paragraph.

[POST] ~/api/WebChat/Text - Sends a text contribution from the client (in the SentenceModel structure - see the previous paragraphs); it returns nothing (with indication 204 OK); messages are sent as the M_Sentence type.

[POST] ~/api/WebChat/Data - sents the data (Text field) from client app (in SentenceModel structure - see prev. paragraphs); no return values (204 OK indication is present); messages being sent as M_CoBrowsingData type; data are being handled to the co-browsing window on the agents side, interpretted only in the destination window

[POST] ~/api/WebChat/Typing/true - Sends information that the client has begun to write a post; it returns nothing (with indication 204 OK).

[POST] ~/api/WebChat/Typing/false - Sends information that the client has stopped writing a post; it returns nothing (with indication 204 OK).

[POST] ~/api/WebChat/Stop - Indicates that the chat ended (dissociates ChatId from TrackingCookie by closing the conversation); it returns nothing (with indication 204 OK); Note: It is not normally assumed that the visitor would end the conversation in any way, rather only hide it.

Possible additional server responses are as follows:

  • 400 Bad Request - An error occurred while processing the request.

  • 410 Gone - The given chat has already ended and it is necessary to send the Start request again.

References

This section contains a reference to the individual areas of WebChat’s appearance and behavior configuration.

JSON object attributes

Possible JSON object attributes for the WebSite template that WebChat uses.

General principles:

  • Attributes that set dimensions, time values and on/off switches – If they are not in the JSON object, they are automatically set to default values.

  • Attributes that set icons and images – If you set them to "" (empty string ) or delete them, then the corresponding icon or image is hidden.

Basic attributes

Attribute

Description

BlockedChatOnBusyAndClosed

Whether to prevent the visitor from starting a chat with the message LL BusyBlockedChat (busy status) or ClosedBlockedChat (closed status).

  • true or false

  • recommended value true (disable)

RefreshTimeAfterCloseStatus

How long the visitor will see the LL StatusClosed message. After the time expires, the visitor can resume the chat.

  • in ms

  • when 0 is entered, LL StatusClosed is not displayed at all

  • the recommended value is 5000 (5 seconds)

HeaderAgentAvatarShow

Whether to display the agent avatar in the chat header.

  • true or false

  • recommended value: true

HeaderIconAvatar

Image of the agent’s default avatar. The default avatar is displayed until the agent connects with their own avatar.

  • URL to the image or the image as a DataURL (data\:image/img;base64,...)

HeaderIconAvatarUrl

A path to the avatar file on the WebChat server. E.g. /Content/img/##AgentId##.jpg., where ##AgentId## is replaced by the agent ID (GUID). The supported format is PNG or JPG; the avatar cannot be in the SVG format.

HeaderOpenBottom

! Discarded attribute no longer used ! The smallest height of the WebChat window in px. Even if the browser window is smaller than this value, the WebChat window will not shrink. If the browser window is larger than this value, it is not used.

  • The recommended value is 300 px

HeaderClosedBottom

! Discarded attribute no longer used ! A position of the WebChat window from the bottom edge of the browser in px (CSS attribute bottom).

  • The recommended value is 5 px

HeaderIcon

An image of the default chat icon. It is always displayed when the chat is minimized. When the chat is open and maximized, it is displayed unless HeaderAgentAvatarShow is set.

  • HTML tag <img> with URL or DataURL of the image

HeaderIconMinimise

Minimization icon image.

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

HeaderIconMaximise

Maximization icon image.

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

HeaderIconClose

Chat closing icon image.

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

ThumbUpIcon

Illustration of a rating icon (thumbs up).

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

ThumbDownIcon

Illustration of a rating icon (thumbs down).

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

EmoticonsIcon

Emoticon icon image.

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

AttachmentIcon

Attachment icon image.

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

SendButtonIcon

An image of an icon on the Send Message button.

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - error (the button would not be displayed, so it would not be possible to send a chat)

CloseIcon

An image of a popup window close icon (such as an emoticon).

  • HTML tag <img> with URL or DataURL image

  • empty string ("") - the button will not be displayed

Emoticons

A list of icons that will offer icons for inserting an emoticon. The icons must be like characters, not escape sequences.

  • a string of semicolon-separated characters, such as "😁; 😂; 😐; 😉; 😒; 😬; 😞; 😪; 😲; 😡; 😴; ⌚; 💡; 👍; 👎; 💰;"

Copyright logo image.

  • URL or DataURL of the image, not the <img> tag

EndChatWithRatingShow

Whether the visitor will be shown an option to rate at the end of the chat and in what style. Possible values:

  • emoji - three smileys (negative, neutral, positive)

  • stars - five stars

  • thumb - thumbs up/ down rating

  • none - rating will not be displayed

ContentWelcomeTextShow

Whether the LL Welcome text should be displayed when the chat window with the form is opened.

SignalFreeBackColor,SignalBusyBackColor, SignalClosedBackColor, StatusPilotBackColor, StatusICRBackColor, StatusWaitingBackColor, StatusAlertingBackColor, StatusAnsweredBackColor, StatusClosedBackColor

Color the header background according to the chat status. Usually all states are the same color.

  • values as accepted by the browser (e.g. hexa #36377, name navyblue, etc.)

FailedToSendTextColor

The background color of the message text box if it cannot be sent.

  • values as accepted by the browser (e.g. hexa #36377, name navyblue, etc.)

SentenceHtmlOut

HTML template for displaying one inbound message from an agent.

Warning

We do not recommend changing this.

SentenceHtmlIn

HTML template for displaying one outbound message from the user.

Warning

We do not recommend changing this.

DataAppliedHtml

An HTML template for rendering a separator between messages when co-browsing. The ##Literal## placeholder is replaced by the CoBrowsedData literal.

NavigationAppliedHtml

An HTML template for rendering a separator between messages. The ##Literal## placeholder is replaced by the RemoteNavigation literal.

HTML for scenario rendering

Placeholders in settings templates:

Attribute

Description

LabelOnly

HTML template for creating a LABEL form element

TextArea1

HTML template for creating a TEXTBOX form element

TextAreaN

HTML template for creating a TEXTAREA form element

DropDown

HTML template for creating the DROPDOWNLIST form element

DropDown.Option

HTML template for creating the OPTION form element DROPDOWNLIST

CheckBoxes

HTML template for creating a <div> wrapper for the CHECKBOX form element

CheckBoxes.Item

HTML template for creating a CHECKBOX form element

RadioButtons

HTML template for creating a <div> wrapper for the RADIO BUTTON form element

RadioButtons.Item

HTML template for creating a RADIO BUTTON form element

GradeThumb

HTML template for creating a <div> wrapper for rating elements - thumbs up/down

GradeThumb.Item

HTML template for creating a rating form element - thumbs up and down

GradeStars

HTML template for creating a <div> wrapper for rating elements - asterisks (1 to 5)

GradeStars.Item

HTML template for creating a rating form element - asterisks

GradeNumber

HTML template for creating a <div> wrapper for rating elements - numbers (1 to 5)

GradeNumber.Item

HTML template for creating a rating form element - numbers

GradeEmoji

HTML template for creating a <div> wrapper for rating elements - smileys (default 3 - positive, neutral, negative)

GradeEmoji.Item

HTML template for creating a rating form element - smiley

SubmitButton

HTML template for creating a BUTTON form element for submitting a form

ResultOK

HTML template for creating a message that the form is OK (valid).

ResultFail

HTML template for creating a message that the form contains errors (not valid).

ValidationText

HTML template for creating a message for an element that contains errors (not valid).

The message text must be hidden by default using the CSS class. The recommended CSS class name for hiding is hidden.

ValidationHiddenClass

The name of the CSS class that hides the validation message in the ValidationText parameter.

If an error occurs, JavaScript removes this element class, which causes the error to be displayed.

The recommended name is hidden.

Default JSON settings

The default JSON attribute values can be found in the attached JSON file.

Setting up Snippets within a webchat

Shortcut configuration for snippets can be done in administration, Configuration section, via SnippetStartChar and SnippetCommitCharacters params.

Configure permissions in the administration in the Roles section, specifically EditSnippetText.

Defined snippets are stored in the Perso database table; if you delete user data in this table, it will be lost.

Note

Chat topics, selectable in template, are handled by DropDownTopicsDataQueryId; for crew members it is called DropDownCrewsDataQueryId. Sample underlying queries located in Standard-DropDowns.sql.
